DESCRIPTION
Center Rock Inc’s Hydro-Jaw 1200 Breakout/Make-up Machine uses a heavy-duty chain link jaw design to quickly breakout or make-up bits, DTH hammer joints, and other API tool connections to keep your operation running smoothly.
The Hydro-Jaw 1200 Breakout/Make-up Machine is powered by a Honda 5.5 horsepower gasoline engine linked to a single-stage hydraulic pump, the model 1200 unit is portable and easily moved around the job site. It is designed to safely operate in the horizontal or vertical position. A lifting eye and forklift slots make it easy to load and unload. Diesel and electric units are available, electric units in 230 volt single phase and 230 or 480 volt 3 phase. Both units run quieter, with no exhaust fumes and with less vibration than the gas or diesel models.
With its excellent power and adjustability, the CRI Model 1200 is ideal for breakout / make-up in a wide range of drilling applications.
TECHNICAL DATA
| Specifications | |
|---|---|
| Standard Range | 5.5″ OD to 12″ |
| Optional Jaw Package | 3″ OD to 5.5 |
| Weight | 1,500 lbs |
| Shipping Weight | 1,900 lbs |
| Length (Without Handle) | 51″ |
| Length (With Handle) | 69″ |
| Height | 50″ |
| Width | 32″ |
| Breakout Torque | 60,000 ft lbs |
| Make-Up Torque | 50,000 ft lbs |
| Heavy Duty Jaw Links |
ABOUT CENTER ROCK
Center Rock’s priority is to get you down the hole safely, productively, and efficiently.
They make and distribute a complete line of air-drilling tools, services, and accessories. Leading global drilling, oil-and-gas, construction, mining, and foundation contractors trust them for optimum performance, even in the most challenging operating conditions.
Center Rock was founded in 1998 by Brandon Fisher, a former Ingersoll-Rand sales rep for the East Coast. Fisher knew the drilling industry lacked a product provider that could also quickly react to customer on-site needs. In other words, he built Center Rock as a servicing manufacturer.
“We’re always looking for the next best way to drill into the earth – and that ongoing search fuels my excitement,” claims Fisher.
President & CEO Dave Pietrzykowski (Dave P) says; “Challenge us and you will be pleasantly surprised with how rapidly we can respond when it comes to designing, manufacturing, and delivering quality drill bits, downhole drills, accessories, and other specialty drilling products. More and more drillers are choosing Center Rock products to help get the job done right.”
Rudy Lyon, Lead Product Designer for Center Rock, drives their Rock Drilling research, design, development, marketing, and operations activities. He holds numerous downhole and water-powered rock drilling patents.
Warren Lay, their Design Engineer, has more than a quarter of a century of actual drilling expertise. Dan Stoner is their key point of contact for product innovations and sales for the oil-and-gas market. Both of these men are highly skilled at solving the toughest customer problems – right in the field.
Breakthrough innovation, Superior products and services. Outstanding technical support. Genuine drilling expertise. Delivering the ultimate impact: Center Rock!
For more information and pricing, please request a quote.
