DESCRIPTION
245 Copper Tool Joint Compound 1 Gal is a lead free, zinc free, quality lubricating compound that handles high temperatures and provides anti-seize performance required for breaking in new tool joints and lubricating drill collars. 245 Copper Tool Joint Compound 1 Gal is used in all drilling and anti-seize applications in the petroleum industry including refineries, petrochemical plants, and the water well industry. 245 Copper Tool Joint Compound is recommended for use on rotary shouldered connections and provides protection against galling and seizing or damage to threads on drill collars and tool joints, even under the most demanding conditions, including the deepest, hottest wells. It eliminates the need for wire brushing of threads to remove buildup often experienced with compounds that contain lead or zinc.
245 Copper Tool Joint Compound assures constant makeup torque, is effective when used on downhole production tools or pumping equipment, and is recommended for use in areas
of high temperatures.
BENEFITS
â–ª Used in horizontal drilling applications
â–ª Protects against galling
â–ª Also used in anti-seize applications in petroleum industry
â–ª For water well drilling operations
â–ª Recommended for use on rotary shouldered connections
â–ª Eliminates the need for wire brushing of threads to remove buildup
â–ª Excellent pumpability
APPLICATION
245 Copper Tool Joint Compound is recommended for drill collars, drill pipe, tool joints, rotary- shouldered connections, tubing, casing, and fishing tools. 245 Copper Tool Joint Compound is also recommended for application to stainless steel connections as well as threaded and flanged connections in steam injection, primary recovery, and fire flood wells.
TYPICAL OBSERVATIONS
Color Copper
Texture Smooth
Density, lb/gal@ 77°F (25°C) 9.25
Specific Gravity @ 77°F (25°C) 1.108
Dropping Point, ASTM D-2265 320°F (160°C)
Flash Point, ASTM D-92 >400°F (>204°C)
Penetration, ASTM D-217 @ 77°F (25°C) 345–355
Base Oil Viscosity
cSt @ 40°C 32
Evaporation Loss,
ASTM D-972 @ 210°F (98°C) 0.2%
Oil Separation, ASTM D-1742 @ 77°F (25°C) Nil
4-Ball, Weld Point, Kgf (ASTM D-2596) 620 Typical
Temperature Range -32°F to 300°F
(-35°C to 149°C)
Friction Factor, API RP 5A3 Annex I 1.0
Salt Spray Test, ASTM B-117 1000+ hours
Brushable To -20°F (-29°C)
Shelf Life (unopened container) Four years
